Liberty

Liberty

Versatile and reliable, designed for superior performance and low glare

Product Code: LIB Categories: , , Tags: , , , ,

The Liberty is an ultra-versatile downlight collection available from Digilin. Well regarded for its efficiency and reliability the Liberty has earned the nickname “Bulletproof” and is commonly used in commercial, medical and infrastructure projects where significant light levels and uniformity are required.

Australian designed and manufactured, with class-leading light output ratios, the Liberty is an outstanding example of electronic lighting engineering. Multiple outputs, colour temperatures and beam angles make it extremely easy to arrive at the perfect downlight solution for any project. Also available with cyanosis observation LED (COI <1.8).

Clear
Datasheet

Specifications

Model 800 1200 1600 2200 2800
Colour Temperature 2700K-5700K 2700K-5700K 2700K-5700K 2700K-5700K 2700K-5700K
Delivered Lumens 785-986lm 1049-1319lm 1407-1754lm 1844-2317lm 2402-3018lm
Luminaire Power 5.9W 8.9W 11.8W 17.5W 25.3W
Connected Load 7.3W 10W 14.5W 20.2W 27.9W
Drive Current 180mA 270mA 350mA 500mA 700mA
Forward Voltage 32.5V 33V 33.8V 34.9V 36.1V
CRI 90 (80 – 5000K)
Performance L90 >55,000hrs
Beam Option64°, 18°, 35°
Finish Colour,
ControlBluetooth, DALI, DMX, Mains/Phase, SDALI
MountingRecessed
StyleFixed
Driver OptionsRemote
Build MaterialCast Aluminium
IP RatingIP20
Dimensions102mm (Trim), 66mm (Light Emitting Area), 113mm (Height)
Hole Cut Out90mm
Weight580g
