Flexible, durable linear for creative applications

Product Code: HFF/HFS Categories: , , Tags: , , ,

HaloFlex breaks through the normal design limitations of linear systems by forming curves and allowing light to become art.

Designed for decorative applications where a refined finish is critical, HaloFlex’s brings a multitude of options to the table. Available in 2700-4000K, RGB, RGBW and variable white, the flexible linear profile provides limitless possibilities for creative designs.

Please contact Digilin’s sales team for advice regarding connection options.

Clear
Datasheet

Specifications

Illumination Type Front-lit/Side-lit
Colour White RGB RGBW Variable White
CCT/Wavelength 2700K, 3000K, 4000K Red: 618-624nm
Green: 522-528nm
Blue: 468-474nm
Red: 618-624nm
Green: 522-528nm
Blue: 468-474nm
White: 2700-4000K
2200-5700K
LED Lumens 280-850lm/m 155-400lm/m 255-490lm/m 220-270lm/m
Power 12W-15W/m 12W/m 15W/m 12W/m
Voltage 24VDC 24VDC 24VDC 24VDC
IP Rating IP67/IP68 IP68 IP68 IP67
Operating Temperature -20 to 45°C -20 to 45°C -20 to 45°C -40 to 55°C
Beam Angle 120° 120° 120° 120°
Material Silicone/PVC PVC PVC Silicone
Module Length 55.6- ~83.3mm ~83.3-100mm ~83.3-100mm ~83.3mm
Minimum Bend Radius 120-300mm 120-300mm 120-300mm 300mm
Maximum Continuous Feed 10m Single, 20m Dual 7m Single, 14m Dual 5m Single, 10m Dual 15m Single, 30m Dual
Width 11.5-16mm 11.5-16mm 11.5-16mm 16mm
Height 17-21mm 17-21mm 11.5-16mm 17mm
